IE_S-1WR3
This product series is specifically designed for applications in on-board power supply systems that require a voltage isolated from the input power source.
1. Fixed-voltage input, isolated regulated-voltage dual outputs
2. Isolation voltage: 3000 VDC, power: 1 W
3. Compact SIP package, plastic housing
4. Output short-circuit protection, automatic recovery
IE_S-1WR3 series
| Model No. | Power(W) | Isolation Vol.(VDC) | Input Voltage(VDC) | Output Voltage(VDC) | Dimension(mm) | Package | Datasheet |
|---|---|---|---|---|---|---|---|
| IE0505S-1WR3 | 1 | 3000 | 5（4.75-5.25） | ±5 | 27.50*9.50*12.00 | SIP |  |
| IE0512S-1WR3 | 1 | 3000 | 5（4.75-5.25） | ±12 | 27.50*9.50*12.00 | SIP | |
| IE1205S-1WR3 | 1 | 3000 | 12（11.4-12.6） | ±5 | 27.50*9.50*12.00 | SIP | |
| IE1212S-1WR3 | 1 | 3000 | 12（11.4-12.6） | ±12 | 27.50*9.50*12.00 | SIP | |
| IE1215S-1WR3 | 1 | 3000 | 12（11.4-12.6） | ±15 | 27.50*9.50*12.00 | SIP | |
| IE2405S-1WR3 | 1 | 3000 | 24（22.8-25.2） | ±5 | 27.50*9.50*12.00 | SIP | |
| IE2412S-1WR3 | 1 | 3000 | 24（22.8-25.2） | ±12 | 27.50*9.50*12.00 | SIP | |
